Aseprite Importers

These tools enable a smooth workflow for the creation of graphical elements in the game.
The main goal is to integrate with Aseprite in a way that promotes quick iterations, starting from a visual draft and evolving game scripting and graphics together as things take shape.

Importers are available for Characters and Rooms, allowing an almost one-click creation of the complete room structure.

Next releases will introduce an Importer for Inventory items too.

Basics

The plugin works by reading tags from a properly organized Aseprite source file and using that information to populate the target Popochiu Object in a single pass.

The result of the process differs depending on the target object type:

• For Characters, every tag represents a specific animation (ex. the talk animation), and when applicable, the animation direction (ex. up, down, left or right). So in a typical project of medium size, there will be specific tags for talk up, talk down, walk left, walk right, and so on, plus very specific tags for special cutscene animations (eat multifolded pizza, brush alien dog hair, jump across cakes chasm, etc).
• For Rooms, every tag represents a Prop and for each tag, a new prop with its own animation is created and populated by the appropriate animation (or sprite). Background and foreground elements are props, of course, and it will be possible to configure each prop visibility and clickability at import.

Despite having slightly different outputs, the structure of a Character's or Room's Aseprite source file is basically the same.
Let's see examples for both.

Aseprite file organization

Please take a look at the following image:

First notable thing is, a single file contains all animations for the character, identified by tags (marker 1). Each tag will be used to create a single animation, named after the tag, for the Character.

Your file can also be organized in layers (marker 2). Layer names are completely up to you and you may create as many as you like. The importer has an option to import only visible layers, that's useful if you have reference or background layers that you don't want to be part of your sprite.

Layers are particularly useful in Rooms source files, because without them, isolating props tend to become pretty messy. Take a look at the following example.

To keep different props apart, the image is organized in layers (marker 1). In the specific case, layer names and tag names match, but you can of course have situations where more than one layer is necessary to render a specific tag (it's pretty common really); a typical example is the background: in the example above, we could have decided to have the trees on the background prop. The resulting Aseprite file would have looked like this then:

Notice how the Tree tag disappeared and the Tree layer is now present with the Background one in the Background tag.

On the other hand, you can have tags with many frames on the same layer. This is the most common case because you often wants your props to be animated, like in the case of our crackling bonefire (see marker 2 in the image above):

Here we have an isolated fire, composed by 4 frames, all grouped by the proper tag.

Basically all combinations of layers and frames are allowed: what you see in a specific animation if you play the tag in Aseprite, will be imported as is in the Prop.

Back to the tags: you can name them whatever you want, but to get the most out of this functionality, stick to the following conventions:

Case style

You can use snake_case or PascalCase to name your tags, as you prefer. They will be converted to snake_case anyway before creating animations. Since this can change in the future, we strongly advise not to rely on case sensitivity to differentiate between animations!
Be explicit.

Reserved animation names

The engine will automatically recognize the following reserved names and use them properly: idle, walk, talk, grab. All of them take for granted the character is facing right and it will be flipped to the left and used for up and down directions too, unless you don't provide...

Directional suffixes

The engine supports directional suffixes for eight possible directions (up, up-left, left, down-left, down, etc). The complete list of suffixes is _u, _ur, _r, _dr, _d, _dl, _l, _ul. Every animation you want to create (not just the reserved ones) can be made direction-aware by creating it with the right suffixes.

For example, to create a walk animation that supports the four main directions, you create walk_u, walk_d, walk_r and walk_l. If you don't create walk_l, walk_r will be automatically flipped.

Single-animation file

If a file contains no tags, it will be imported as a single animation named default.

Multiple source files

If you are in the need, you may want to separate your character animations over different source files. This is feasible, but keeping everything in a single file is the best option to speed up development by a great amount.
The plugin allows you to set a single source file at a time, so if you have multiple sources, you have to constantly switch between source files, losing your preferences in the process. In addition, you have to trade the ability to reset all animations off for an incremental import (see below).

Importer settings

The Aseprite Importer exposes its configuration under the Popochiu -> Import sections in both the Editor Settings and the Project Settings.

Editor Settings

Editor Settings contain those configurations that may change between team members' local development environment, like the Aseprite command path, and/or that are valid across different projects.

• Enable Aseprite Importer: Allows the user to enable or disable the importer in their editor. Useful to avoid cluttering the inspector or getting errors for those who don't use Aseprite or don't have it available in a specific environment.

  Note

  This option is only available starting from Popochiu 2.0. In Popochiu 1.0 the importer can't be disabled.

• Command Path: This is the single most important setting to make the plugin work. On Windows, this field must contain the full path to Aseprite executable (having the command in PATH won't work due to some Godot limitations on command execution under Windows). In *nix systems (Linux and MacOS), you can choose to provide the Aseprite command (if in PATH) or the full path, as you prefer.
  Anyway, the plugin will check for the correct execution of the command before initializing itself. If something goes wrong, the output panel will give useful information to fix the problem.
• Remove JSON file When Aseprite is invoked by the importing procedure, it generates a JSON file with metadata that is necessary to complete the job, alongside the spritesheet PNG file. This file is then useless and can be safely erased, most of all if you are versioning your code (you are, aren't you?!). If for some reason you want to keep the output file, just unflag this setting.

Project Settings

Among the Project Settings you'll find those you may want to share with your team, and that mostly impact the importing workflow, setting defaults shared by every instance of the plugin.

• Import Animation by Default: When a source file is scanned, a list of the contained tags is populated. For each element in the list, you can choose if you want it imported or not. This is useful if you have half-baked animations or reference tags of some sort. When this setting is flagged, all new animations in the list will be automatically flagged as "to be imported". When this setting is off, they will be flagged as "not to be imported".
• Loop Animation by Default: When a source file is scanned, a list of the contained tags is populated. For each element in the list, you can choose if you want that animation to loop or if it has to be run a single time. Animations like talk or walk are usually looping, but animations specific for cutscenes or special cases may be single runs. When this setting is flagged, all new animations in the list will be automatically flagged as "looping". When this setting is off, they will be flagged as "non-looping".
• New Props Visible by Default: When a Room source file is scanned, a list of the contained tags is populated. For each element in the list, which will be imported as a Prop, you can choose if you want the new prop to be created visible, or invisible (useful for props that have to be shown only at certain conditions). When this setting is flagged, all elements in the list will be automatically flagged as "visible". When this setting is off, they will be flagged as "hidden".
• New Props Clickable by Default: When a Room source file is scanned, a list of the contained tags is populated. For each element in the list, which will be imported as a Prop, you can choose if you want the new prop to be interactive, or non-interactive. When this setting is flagged, all elements in the list will be automatically flagged as "interactive". When this setting is off, they will be flagged as "non-interactive".
• Wipe old Animations: This is the default value for the option with the same name that appears in the importer interface (see below for more information). Set this as you prefer so you don't have to do it all the times, depending on your workflow.

Importer interface

The importer will show a slighlty different interface depending on the target Popochiu Object.

The following sections show examples for both Characters and Rooms, highlighting the small differences.

Opening the Importer

The Character importer tool is visible in the inspector, when you select a PopochiuCharacter object, opening the related scene.

You will not see the importer when you select a character instance in a specific room. To see the importer, you must open the character scene and select its root node.

Likewise, a Room importer is shown in the Room inspector, when you select the root node of an open Room scene.

Using the Importer

When you select a PopochiuCharacter node, you should see this interface in the node inspector, right after the script variables section:

Use Aseprite file field (1) to select the source file. When you do this, the plugin automatically scans the file and lists every tag found (2) (or none if the file is a single animation with no tags).

For each tag that is found and listed, two flags are available (3): Import this animation and Set the animation as looping. Deactivating them can prevent a specific animation to be imported or set the animation as a single-run.

For PopochiuRoom node, the interface is only slightly different, showing two more flags for each tag (1 below):

This prop will be visible and This prop will be clickable flags will make the imported prop visible and interactive, respectively.

The Rescan button at the top allows you to refresh the tags list if you make any changes. It will be your quick-iteration best friend. Rescanning the tags will not overwrite the preferences you already selected for each tag. It will anyway update the frame count references for each animation, get rid of tags that are no more available, and add new ones.

In the Options dropdown (4), you can set some parameters for the importer:

• Output Folder: This refers to the folder in which the TextureAtlas PNG file will be created. If unset, it defaults to the same folder as the scene (in case of a Room Prop, each atlas will be put into the related prop's folder). This helps in case you want to enforce a specific file structure.
• Output File Name: If empty, this will default to the Aseprite original source file name. Should you want to select a different file name for your atlas, specify it here.
• Only visible layers: This flag allows you to ignore hidden layers. Useful if you have reference layers or backgrounds that you don't want to appear in your sprite.

  Tip

  Remember to hide reference layers before saving the source file!

• Wipe old animations: When flagged, all the animations already imported for a Character will be wiped before re-importing them.
  You typically want to keep this setting flagged when you are iterating over a character's graphics and you want to make sure that if you move or rename animations, every possible leftover is removed and the final result is always coherent with the source file, 1-on-1.
  You typically want to unflag this when you are working with multiple source files for a single character, and you want to import animation from a file without getting rid of the animations you have already imported before. Beware that animations with the same name will always be overwritten. If you keep this setting unflagged and you have leftover animations saved for a character you will need to remove them by hand.

All these preferences are automatically saved with the target PopochiuCharacter or PopochiuRoom node, so they are persisted between sessions, and different for each single element.
If for some reason you want to completely reset an Importer anew, just use the Reset preferences button at the very bottom (confirmation required).

Importing animations

Finally, if everything is set up correctly, you can hit the Import button. The importer will do its magic (beware: very large files with hundreds to thousands of frames will take a while to load, manly due to Aseprite exporting them).
When the procedure is over a popup message will report the status and processed tags count.

• For Characters, you will find all your animations in the AnimationPlayer of your character.
  All reserved animations (idle, walk, talk, grab) will automagically be available in your game and used by the engine.
  You can use play_animation() method to play any other animation by passing its name (without directional suffixes) as a parameter.
• For Rooms, you will see a set of props have been created automatically and populated with the correct sprites. If you have animated props (like the fire in this page's example), starting the scene in the player will show the animation running. You can check the animation is correctly looping, if that's the case.
  Note that existing props with the same name will have their animations seamlessly updated by the procedure, preserving any other properties or configuration they may have.
  The Room importer is not yet tracing colliders automatically, but each Prop has an embedded polygon. To edit it, select the Prop in the room tree (or in the Popochiu panel room tab) and click the Interaction Polygon button in the toolbar.
